Ventilating Dehumidifier-GS Series

Ventilating Dehumidifier-GS Series Ventilating Dehumidifier-GS Series Ventilating Dehumidifier-GS Series Ventilating Dehumidifier-GS Series
Indoor humidity produced by human activity(showering, cooking, perspiring, and even breathing) can build up to very high level, it does more than make us uncomfortable. This can encourage the growth of organisms harmful to our health, and over time, it`s bad for the structure and furnishings, such as rusting. Besides, without sufficient ventilation, we cannot be guaranteed with enough fresh air either. At the same time indoor CO2 and other harmful odors cannot drift away.
  • Product Description
  • Download
So here we combine the dehumidifier and ventilator together to provide occupiers with fresh and dry comfortable air. This is Thenow whole house ventilating dehumidifier. GS Series is ducted dehumidifier. Besides, it brings in fresh air and exhausts stale indoor air and realizes heat recovery to save energy.

Features of Ventilating Dehumidification Unit-GS Series

  • Danfoss Reliable Compressor for long hour continuous and stable operation.
  • Imported BLDC EBM motor
  • Air Purification system:
  • Pre filter, Medium Filter, HEPA Filter, Activated Carbon Filter, UV Sterilizing Lamp and Negative Ionizer
  • Unique designed drain pan(positive drainage, no water leakage)
  • Main fan and exhaust fan are both controlled under three speed
  • Equipment filled with environmental friendly refrigerant of R134A.
  • Advance touch sensitive panel with intelligent controller and user friendly operation (Air Quality index display). Standard 485 interface, WIFI available.
  • Automatic defrosting system
  • High static pressure
  • Modular design, easy maintenance

Specifications & Technical Parameter of Whole House Air Purifier Dehumidifier-GS Series

Model Power Supply Air Supply(m/h) Fresh Air Supply Exhaust air volume Power Dehumidification(L/D) Residual pressure(Pa) Air Return+
The sum of the length of outlet duct(M)
Application area(m²)
The height of 2.6 meters
Noise(d/B A) Outline Dimension
(mm)
Diameter of return air outlet(mm) Diameter of fresh air inlet(mm) Air inlet diameter(mm) Diameter of air outlet(mm)
CXJT28/300-GS01 1PH/220V/50Hz 300               0-150                 0-100 0-150 0-100 635 28 60 10 40 49 1205*699*283 ø100 ø100 ø100 ø100
CXJT40/400-GS01 1PH/220V/50Hz 400                     0-200                                                 690 0-150 690 40 70 15 60 55 1205*699*283 ø150 ø150 ø150 ø150
CXJT40/400-GS01 1PH/220V/50Hz 500               0-250                 0-200 0-250                         0-200 1180 60 80 18 100 58 1205*699*283 ø150 ø150 ø150 ø150
CXJT40/800-GS01 1PH/220V/50Hz 800               0-350                 0-300 0-350                           0-300                            130 2070 120 80 18 130 62 1330*749*325 ø200 ø200 ø200 ø200

Leave a Message Email Us

we will contact you within 24 hours.

Ventilating Dehumidifier-GS Series Application
