Floor Standing Ductless ERV/HRV With ESP System - CF Series

Floor Standing Ductless ERV/HRV With ESP System - CF Series Floor Standing Ductless ERV/HRV With ESP System - CF Series
Thenow standing ductless energy recovery ventilator with ESP Syetem-CF Series has two types air supply mode,they are straight blow and pipe blow. 550CMH and 1000CMH air flows are available now.
  • Product Description

Features of Floor Standing Ductless ERV With ESP System

  • LCD control with touch screen, easy and convenient
  • EC motor, energy saving and lower noise
  • Nano membrane heat exchanger, exchange rate up to 75%
  • PTC heating system
  • Pure ESP sterilization system without ozone, four-layers high efficiency filtration
  • Automatic control with CO2, VOC, PM2.5, temperature and humidity sensors
  • Floor standing, easy to install

Application of Floor Standing Ductless Ventilation System With ESP System

Residential building ventilation, offices and shops, kindergarten, schools, hotel, senior residence etc.

Technical datas of Floor Standing Ductless ERV Air Exchanger With ESP System

Model

Voltage

Fresh Air
(m³/h)

Air Supply Mode

Enthalpy Efficiency
(%)

Rated Power(W)

Auxiliary Heating Power(W)

Noise dB(A)

Weight(kg)

Appication Area(㎡)

Size
(LxWxT mm)

TSX550-CF01

220V 50Hz

550

Pipe Type

≥75

≤250

800

≤45

110

100~200

526x453x1730

TSX550-CF02

220V 50Hz

550

Direct Blowing

≥75

≤250

800

≤45

110

100~200

526x453x1730

TSXS100-CF01

220V 50Hz

1000

Pipe Type

≥75

≤400

1200

≤55

140

200~300

624x503x2180

TSXS100-CF02

220V 50Hz

1000

Direct Blowing

≥75

≤400

1200

≤55

140

200~300

624x503x2180
