Wine Cellar Cooling Units Through-the-Wall
Thenow through-the-wall wine cellar cooling unit is specially designed to match the demands in foreign markets. It is a ductless wine cellar cooling units with evaporator and condenser are housed together in one unit. It offers a compact design that can be applied to the unique today’s do-it-yourself modern wine cellar or wine wall.
Features:
Compact design, flexible installation;
Quiet and efficient operation;
Build-in wet film pad and PTC heater, better control the temperature and humidity;
Intelligent control panel, famous brand sensors with stable quality, integrated ModBus connection;
Famous brand compressor, safe, stable and low energy consumption;
Traditional Chinese knot design air grille, better heat dissipation.
Technical Data
Model |
Unit |
JT20 |
|
Cellar Size |
Semi Buried |
m³ |
4~7 |
Insulated* |
m³ |
4~12 |
|
Power |
V/HZ |
220V/50Hz |
|
Cooling |
KW |
0.72 |
|
Heating |
KW |
1 |
|
Air Flow |
m3/h |
170 |
|
Static Pressure |
Pa |
30 |
|
Noise |
dB(A) |
42 |
|
Refrigerant |
/ |
R290 |
|
Control |
/ |
PC Full-touch smart control |
|
Temperature |
℃ |
10-18℃, ±2℃ |
|
Humidity |
℃ |
50~70%, ±5% |
|
Total Power |
KW |
1.5 |
|
Humidifier |
/ |
Wet-film |
|
Humidity Capacity |
Kg/h |
1 |
|
Dimension (L*W*H) |
mm |
801*450*379 |
|
Drainage |
mm |
ф20 |
Note: Cellar inside dry-bulb t=12℃ 60% Outside dry-bulb t=35℃,wet-bulb t=28℃
Insulated*: Cellar walls and ceiling insulation with 60mm polyurethane.
Cellar size in above sheet is just experience value. There are several factors such as glass, stone, concrete, insulation, ambient temperature, ventilation etc. which will change the required amount of Kw needed to properly cool your wine room or wine cabinet. We strongly recommend you contact with us or our distributors beforehand to help you to choose the model matched. We do not bear the losses caused by the selection errors caused by the above reasons.
Optional Accessories
Supply & return air flange
